HCG-FS High-Capacity AWEIS Electronic Gas Ignition System | Fire by Design
The High-Capacity AWEIS Electronic Ignition by Fire by Design is a patented all-weather system that is a durable and reliable technology offering a precise ignition point to your gas fire features. Its control box is made from 316 marine grade stainless steel that will withstand all types of harsh outdoor elements. This unique AWEIS system is field serviceable for convenience and has drastically decreased any controller/igniter failures which makes the replacement of any parts much easier and cost-effective.
The High Capacity all weather ignition system is rated for a max output of 510,000 BTUs and has a maximum inlet pressure of 0.5PSI. The valve connection for this model is a 3/4" FPT fitting.
Note: the 24VAC option includes the power supply but the 30VDC model does not.
High Capacity AWEIS Electronic Specifications
| Rated Output | Max output of 510,000 BTU/HR |
| Max Inlet Pressure | 0.5 PSI |
| Valve Connection | 3/4" FPT fitting |
| Material | 316 marine grade stainless steel control safety box |
| Ignition | Hot surface ignition - reliable simple start every time |
| Outlet/Inlet | 3/4" FPT inlet/outlet | 24VAC or 30VDC voltage |
| Valve Dimensions | 4.375" x 4.375" (W x D x H) |
| Includes | Pilot burner assembly, ignition control module, heat deflector shield, and installation instructions |
| 24VAC | Includes a power supply |
| 30VDC | Does not include the power supply |
